Mauldin Commercial Asphalt Paver
1360
Versatile commercial paver with 4 ft to 8 ft paving widths, 74 HP Tier 4 Final diesel power, 5.5 ton hopper capacity, and sonic auger control.
Overview
Built for the way Texas crews work
The Mauldin 1360 is a narrow-width commercial paver built for versatility, service access, and high mat quality in confined paving work.
With 4 ft to 8 ft paving widths, a 74 HP Tier 4 Final Deutz engine, 5.5 ton hopper capacity, and standard sonic sensor auger control, the 1360 is a strong fit for paths, shoulders, utility repair, municipal patching, and compact commercial work.
Paving widths from 4 ft to 8 ft.
74 HP Tier 4 Final Deutz diesel engine.
5.5 ton hopper capacity.
Heaviest screed in class for mat quality.
Designed for easy-access serviceability.
Standard sonic sensor auger control.
Key Specs
- Paving width
- 4 ft to 8 ft
- Hopper capacity
- 5.5 tons
- Operating weight
- 13,000 lb
- Engine
- Deutz Tier 4 Final
- Power
- 74 HP
- Paving speed
- 0 to 140 fpm
Field Details
See the machine at work
Close-up photos and jobsite views show how the machine is built, configured, serviced, and used beyond the spec sheet.
Narrow-width paving
The 1360 is built around 4 ft to 8 ft work where larger pavers are too wide or too heavy.
Service access
Mauldin positions the 1360 with easy-access serviceability to reduce downtime on municipal and commercial jobs.
Sonic auger control
Standard sonic sensor auger control helps manage material delivery at compact paving widths.
Technical Specifications
1360 Spec Details
Specifications below are pulled from manufacturer materials and Closner product research. Final build details can change by chassis, configuration, and option package.
Dimensions and capacities
- Length
- 14 ft 4 in
- Width
- 9.2 ft with hopper opened
- Height
- 75 in
- Weight
- 13,000 lb
- Screed weight
- 2,000 lb
- Truck clearance
- 22 in
- Fuel tank
- 22 gal
Paving system
- Paving widths
- 4 ft to 8 ft
- Paving depth
- 6 in
- Heating source
- Electric heat
- Augers
- 12 in diameter
- Paving speed
- 0 to 140 fpm
- Travel speed
- 0 to 180 fpm
- Track pad width
- 8 in
Features
1360 advantages
4 ft to 8 ft paving
A compact paving range makes the 1360 useful for shoulders, paths, utility repairs, and restricted commercial work.
74 HP Tier 4 Final
The Deutz diesel provides the horsepower listed for the 1360's compact tracked platform.
5.5 ton hopper
A 5.5 ton hopper provides useful material capacity for a narrow-width paver.
Gallery
1360 Photos
Factory model photos and system views for a closer look at the machine.
FAQ
Common 1360 Questions
What width does the Mauldin 1360 pave?
Mauldin lists the 1360 for 4 ft to 8 ft paving widths.
What engine is in the 1360?
The official page lists a Tier 4 Final Deutz diesel rated at 74 HP.
What is the 1360 hopper capacity?
The Mauldin 1360 is listed with a 5.5 ton hopper capacity.
