Putzmeister Shotcrete Machines
Wetkret 3
Reliable shotcreting system which is designed for every kind of area
Overview
Built for the way Texas crews work
The mechanised concrete spraying system Wetkret 3 is designed for shotcreting in small tunnel sections with difficult access. Mounted on a compact crawler chassis with a 24 hp (17.9 kW) Diesel engine, the equipment features hydraulically operated support legs and an optional +/-30 tilting system, guaranteeing stable operation in ascending and descending slopes. The telescopic spraying arm with a maximum horizontal reach of approx. 23' permits working in minimum sections of 8' 2" and is operated by remote control (dual use by cable and wireless).
Wetkret 3 can be easily and quickly connected to the Putzmeister concrete pump, air and additive supply, in a way that prevents the use of external hoses interfering with the work.
Far reaching: spraying arm providing 23' (7 m) horizontal spraying reach
Designed to work easily and safely in areas with difficult access
Stable transport and operation in any terrain: rubber-tracked crawler carrier with hydraulically operated support legs
Proportional remote control: dual use by cable or radio remote control
Connection for concrete pipes on both sides, no disturbing hoses for air and additive supply on the sides
Tilting system to keep the machine in horizontal position in gradients of up to +/- 30 to assure correct spraying angle and stable arm reach
Key Specs
- Length x Width x Height
- ' "
- Weight
- 11023 lbs
- Drive System Electric
- 15 hp
- Engine Power
- 24 hp
- Max. Speed
- 2.24 mph
- Diesel Tank
- 17 gal
- Additive Pump Adjustment Range
- 16-132 gal
- Additive Pump Pressure
- 145 psi
Technical Specifications
Wetkret 3 Spec Details
Specifications below are pulled from manufacturer materials and Closner product research. Final build details can change by chassis, configuration, and option package.
General Information
- Length x Width x Height
- ' "
- Weight
- 11023 lbs
- Drive System Electric
- 15 hp
- Engine Power
- 24 hp
- Max. Speed
- 2.24 mph
- Diesel Tank
- 17 gal
- Additive Pump Adjustment Range
- 16-132 gal
- Additive Pump Pressure
- 145 psi
- Additive Tank
- 47 gal
Pump Configuration
- Nozzle
- 1.57"
Features
Wetkret 3 advantages
Far reaching: spraying arm providing 23' (7 m) horizontal spraying reach
Far reaching: spraying arm providing 23' (7 m) horizontal spraying reach. Wetkret, SPM, Geokret, and gunning systems for sprayed concrete in tunnel, mining, slope stabilization, refractory, and structural repair work.
Designed to work easily and safely in areas with difficult access
Designed to work easily and safely in areas with difficult access. Wetkret, SPM, Geokret, and gunning systems for sprayed concrete in tunnel, mining, slope stabilization, refractory, and structural repair work.
Stable transport and operation in any terrain: rubber-tracked crawler...
Stable transport and operation in any terrain: rubber-tracked crawler carrier with hydraulically operated support legs. Wetkret, SPM, Geokret, and gunning systems for sprayed concrete in tunnel, mining, slope stabilization, refractory, and structural repair work.
Proportional remote control: dual use by cable or radio remote control
Proportional remote control: dual use by cable or radio remote control. Wetkret, SPM, Geokret, and gunning systems for sprayed concrete in tunnel, mining, slope stabilization, refractory, and structural repair work.
Gallery
Wetkret 3 Photos
Factory model photos and system views for a closer look at the machine.
FAQ
Common Wetkret 3 Questions
Is the Wetkret 3 available through Closner?
Closner can help source new Putzmeister equipment, verify current factory availability, and support parts, service, and application planning for Texas jobsites.
What should I confirm before quoting a Wetkret 3?
Confirm material mix, target output, placement distance, vertical reach, jobsite access, power or chassis requirements, support footprint, and the service plan for the machine configuration.
